Inhouse product
Why Buy From us?
· True color display
· Resolution is up to at 1366*768
· Wide view of field:178°(H)/ 178°(V)
· Specific menu design, which is simple to operate
· Support 7*24 working and lower power consumption
· Adaptively recognize signal
· VESA stand bracket
· Support multiply language
| Panel | |
|---|---|
| UNV Panel size | 18.5 |
| UNV Resolution | 1366*768 |
| UNV Brightness (cd/m²) | 240 |
| UNV Contrast ratio | 600:1 |
| UNV Color support | 16.7M |
| UNV Viewing angle (H/V) | 45°/45°(CR≥10) 25°/40°(CR≥10) |
| UNV Pixel Pitch(mm) | 0.3*0.3 |
| UNV Refresh Rate | 60Hz |
| UNV Ratio | 16:9 |
| UNV Panel Type | LED Backlight |
| UNV Color bit | 8 |
| UNV Display size(mm) | 409.8×230.4 |
| UNV Operation Hour | 24/7 |
| Touch | |
| UNV Response time (ms) | 5 |
| General | |
| UNV Standby power consumption (W) | ≤0.3(Standby) |
| UNV Operating temperature | 0°C ~ 40 °C |
| UNV Operating humidity | 5%~95% (No Condensation) |
| UNV Storage temperature | -10°C ~ 50°C |
| UNV Product dimensions (W*H*D)(mm) | 447*276*46 (No Pedestal) 447*351*200 (With Pedestal) |
| UNV Packaging (W*H*D)(mm) dimensions | 486*93*374 |
| UNV Weight (kg) | Net Weight:2 Gross Weight:3 |
| UNV Input Voltage | DC 12V, 2A |
| UNV Typical power consumption (W) | 12.73 |
| UNV Altitude | ≤5000m |
| Interface | |
| UNV Video Input | 1* VGA、1* HDMI |
